SWITCH IeV4

SWITCH IeV4: The future of Sustainable Logistics

The IeV4 from SWITCH Mobility redefines efficiency with a 1.75-ton payload, a 130 km* range, and a 310V high-voltage EV architecture for superior performance. Powered by a 60 kW motor and a 32.2 kWh lithium-ion battery, it ensures lower operating costs, reliable performance, and a profitable TCO. Features like regenerative braking, electric power steering, and SWITCH iON telematics meet the demands of modern logistics.

KEY FEATURES:

  • 1.75 Ton Payload
  • 130 kms Range*
  • 32.2 KWh Lithium-ion battery
  • 310V High Voltage EV Architecture
  • 60 kW / 230 Nm torque
  • Profitable TCO

Technical Specifications

Model Details

  • GVW (kg)
  • 3490
  • Payload(kg)
  • 1750(FSD)
  • Wheelbase (mm)
  • 2590
  • Load Body Dimension-FSD (mm)
  • 2951 x 1750 x 488 (9ft 8in X 5ft 9in X 1ft 7in)
  • Container Suitability
  • 340 CFT Container Suitability (Outer)*

EV Power Train Details

  • Battery
  • 32.2 kWh Advanced Lithium-ion Battery
  • Operating Voltage (V)
  • 300V EV Architecture
  • Motor
  • Permanent Magnet Synchronous Motor (PMSM)
  • Peak Power (kW)
  • 60
  • Peak Torque (Nm)
  • 230

Performance

  • ARAI Certified Range (km)
  • 206*
  • Real World Range (km)
  • 130*
  • Max. Geared Speed (kmph)
  • 80
  • Gradeability (%)
  • 22

Charging Details

  • Charger Type
  • CCS2 (AC & DC)
  • DC Charging
  • 55 mins (10% to 80% Charging)
  • AC Charger (32A)
  • 4 hrs ( 0-80 % SOC)*
  • AC Charger (16A)
  • 9 hrs ( 0-80 % SOC)*

Others

  • Seating Capacity
  • D+2
  • Ground Clearance (mm)
  • 206
  • Steering
  • Electric Power Steering
  • Tyre - Front & Rear
  • 7.00 R15 LT 12 PR Radia
  • Front Suspension
  • Rigid Suspension + Parabolic Leaf
  • Rear Suspension
  • Rigid Suspension + Semi Elliptic Leaf
  • Brakes
  • Front - Disc | Rear - Drum
